Description
The fifth and latest generation of the world's most popular single-board computer, comes with a revolutionary processing architecture and 4GB RAM to provide a performance that exceeds previous generations by more than two to three times.
The Raspberry Pi 5 - 4GB board is the giant engineering leap and the absolute Benchmark standard for building Artificial Intelligence (AI) applications, computer vision processing, and complex automation systems. The board is equipped with a quad-core Broadcom processor with a solid frequency of $2.4\text{ GHz}$, supported by an advanced graphics processor that supports running two screens with a resolution of $4\text{K}$ and a refresh rate of $60\text{Hz}$ simultaneously with complete smoothness and without any stuttering.
For the first time in the series' history, the board features an internally designed I/O Controller chip (RP1 I/O Controller), which gives the GPIO ports a qualitative leap in data transfer speed and response rates, in addition to supporting a PCIe 2.0 port for directly connecting ultra-fast NVMe drives. The board is equipped with dual-band Wi-Fi and Bluetooth 5.0 wireless communication technologies, with a built-in mechanical power button and a dedicated port for real-time clock (RTC). It is the professional and sole choice for software engineers and developers, cybersecurity experts, and mechatronics graduation projects to build self-hosted web servers, Edge Computing systems, and advanced autonomous driving robots.
Quick Technical Specs
-
Central Processing Unit (CPU): Broadcom BCM2712 quad-core processor (Quad-core ARM Cortex-A76) with a frequency of $2.4\text{ GHz}$ with 64-bit architecture.
-
Random Access Memory (RAM): 4GB (4GB LPDDR4X-4267) high-speed capacity.
-
Graphics Processing (GPU): VideoCore VII processor supporting OpenGL ES 3.1 and Vulkan 1.2 libraries.
-
Display and Screen Outputs: Two Micro-HDMI ports supporting the simultaneous operation of two $4\text{K}$ and $60\text{Hz}$ screens with full audio support.
-
Wireless Communication Technologies:
-
Advanced Interfaces and Expansion Ports:
-
Integrated PCIe 2.0 x1 port (dedicated for connecting M.2 NVMe SSDs via expansion boards).
-
Very fast wired local network port (Gigabit Ethernet).
-
Two USB 3.0 ports (supporting 5Gbps data transfer simultaneously) + two USB 2.0 ports.
-
Standard GPIO ports (40-Pin) supported by the RP1 chip for ultra-fast sensor response.
-
Power Management and Additional Features: USB-C power port (requires 5V/5A for full functionality), integrated power on/off button, smart 4-wire PWM cooling fan port, and battery port for RTC.
The next-generation Raspberry Pi 5 single-board computer, engineered with a powerful 64-bit architecture and 4GB of high-speed LPDDR4X RAM to deliver 2-3x the processing throughput of previous generations. Standing as the definitive hardware benchmark for enterprise embedded design and edge AI compute, this flagship board features a quad-core Broadcom BCM2712 processor clocked at 2.4 GHz, paired with an advanced VideoCore VII GPU to drive dual 4K60 display arrays simultaneously. Fortified with the custom-designed RP1 I/O controller, it revolutionizes peripheral bandwidth, introduces a native PCIe 2.0 interface for ultra-fast NVMe storage, and includes dual-band Wi-Fi and Bluetooth 5.0 BLE telemetry. Complete with a dedicated onboard hardware power button and real-time clock (RTC) terminal, it serves as an indispensable processing brick for advanced computer vision grids, private network servers, and academic STEM mechatronics laboratories.
